Load Systems International Wireless Load Cell

LSI Wireless Load Cells

MSRP Price $1,836 – $7,900

BTS Price $1,469 – $6,329

Please Choose Size:

5,000 lbs. (<1/2" wire rope size) $1,469.00 USD 12,000 lbs. (1/2" to 5/8" wire rope size) $1,499.00 USD 18,000 lbs. (3/4" wire rope size) $1,719.00 USD 35,000 lbs. (7/8" to 1-1/8" wire rope size) $2,329.00 USD 60,000 lbs. (1-1/8" to 1-1/2" wire rope size) $2,779.00 USD 100,000 lbs. $4,619.00 USD 170,000 lbs. $6,329.00 USD

• Standard single part line pull sizes include: 5,000 lb, 12,000 lb, 18,000 lb, 35,000 lb, 60,000 lb, 100,000 lb, 170,000 lb
• Direct Sequence-Spread Spectrum-Two Way Communication
• Transmission Range: 4,000 feet; 1,300 meters
• Ships as standard with 1-"D" Cell lithium battery, 2-4 years battery life
• Users can replace lithium battery with "D" Cell alkaline battery if lithium replacement battery is unavailable when battery goes low. Battery life is 6 months to 1 year using alkaline
• Each load cell ships pre-calibrated eliminating the needs for test weights
• Operating temperature: -30F to +180F; -35C to +85
• 2 year warranty against defects
• Accuracy is .1% on a single part of line, 1% on a multi part

Information:

Brochure

Specifications
